Stage 1 NSR Camshaft 03-08 Chrysler / Dodge / Jeep 5.7L Hemi Engines

Part Number 112-300-11 (132602751)
Package contents: 1 Each per Box
Select vehicle for guaranteed fit
MADE IN USA
$608.95

In stockShips by 19th Nov

Description

The Gen III Hemi market is rapidly expanding, and the HRT Camshaft Series uses the newest and most advanced lobe designs from COMP Cams in order to produce some of the highest average power and torque camshafts available for these engines. The “Low Shock Technology” features lobe profiles designed to maximize horsepower while improving stability at higher RPM. These profiles are also easier on the valve springs, enhancing durability and reducing load loss. The new HRT Camshafts receive the Micro Surface Enhancement (MSE) finishing process as a standard feature, which increases strength and performance by reducing surface peak roughness and provides a 250% improvement in the effective load bearing area, allowing for much higher loads. Organized into stages, these new options range from mild to wild! All HRT Stage 1 Camshafts are No Springs Required, which keeps cost down while still providing awesome horsepower increases over stock. Stages 2 and 3 applications work with COMP Cams Beehive and Conical Valve Springs, but COMP Cams is also introducing new HEMI Valve Spring Kits, engineered to produce the most power and RPM of any current options.

Features & benefits

  • Melling offers a full line of OE replacement and high performance camshafts for cars, light duty, medium duty and heavy duty trucks. Melling listings include OEM applications to match the engine requirements desired including horsepower, economy and needed engine torque. Melling camshafts are developed, engineered, tested and manufactured with the highest standards of quality and materials.
  • Stage 2 available under 112-303-11. Stage 3 available under 112-305-11.

Specifications

Advertised Exhaust Duration 271 dd
Advertised Intake Duration 269 dd
Assembly Lubricant Included No
Barcode 00036584401964
Basic Operating RPM Range 1,500-6,200 r3
C.A.R.B. E.O. Number N/A
C.A.R.B. Exempt For On-Road Vehicles? No
C.A.R.B. Exemption Reason N/A
Cam Type Hydraulic Roller
Camshaft Material Billet Steel
Camshaft Series HRT NSR
Country Of Origin USA
Dimensions 23.3" x 2.9" x 2.9"
Engine Family Dodge 5.7L & 6.1L HEMI (2003-08)
Exhaust Duration At .050 Inch Lift 222 dd
Exhaust Valve Lift 0.495 in
Intake Duration At .050 Inch Lift 216 dd
Intake Valve Lift 0.5 in
Lifter Type Hydraulic Roller
Lifters Included No
Lobe Separation 113 dd
Stage 1
Street Legal Yes
Valve Springs Required No
Weight 13.4 lbs

Warranty

12 Months

Videos and guides

About COMP Cams

COMP Cams® is the leading American manufacturer of high-quality, performance-based internal engine components, including camshafts, valve springs, rocker arms, lifters, pushrods, and other valve train components. We help our customers with innovative technological advancements through extensive research and development. Our quality workmanship and engineering ensure confidence for racers and street performance enthusiasts. COMP Cams is a proud member of the Edelbrock Group family of brands, which include Edelbrock®, FAST® (Fuel Air Spark Technology), TCI® Automotive, Russell® Performance and Lunati Power®. Headquartered in Olive Branch, Mississippi, COMP Cams remains an innovative American company focused on results-driven technology and superior customer support. We believe in the automotive lifestyle and continue to support the passion for our American pastime. For more information about the Edelbrock Group or any partner brands, visit www.edelbrockgroup.com.

California residents

WARNING: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov.

Carb Status

California carb status to be completed
