NGK Authorized Dealer

OE Series Laser Iridium High Ignitability Spark Plug: DFE Tip, DILFR5A11

Part Number 93759 (132648192)

UPC: 87295937594

Package contents: 1 Each per Box

Select vehicle for guaranteed fit

$18.62

In stockShips by 29th Oct

Description

NGK Laser Iridium High Ignitability spark plugs offer the best combination of performance and longevity. Engineered specifically for OE applications, Laser Iridium High Ignitability spark plugs are tested to the highest standards to ensure quality and durability. Iridium tipped center electrode provides durability six times harder than platinum. NGKs high grade pure alumina ceramic and 98 percent pure copper core prevents the spark plug from overheating while providing reliable starts. Laser Iridium High Ignitability spark plugs feature raised platinum pad or platinum fine wire tip on the ground electrode for even wear in distributorless ignition systems and improved spark performance.

Fitment

This part fits the following vehicles.

2007-2010 INFINITI QX56
2007-2015 Nissan Armada
2007-2019 Nissan Frontier
2012-2020 Nissan NV1500
2012-2020 Nissan NV2500
2012-2020 Nissan NV3500
2007-2012 Nissan Pathfinder
2007-2015 Nissan TITAN
2007-2015 Nissan Xterra
2009-2012 Suzuki Equator

Features & benefits

Pure alumina silicate ceramic insulator provides superior strength and better heat transfer
Trivalent metal plating for superior anti-corrosion and anti-seizing properties
RECOMMENDED USAGE: Best for vehicles with OE DFE iridium alloy plugs
Copper core aids in heat removal
Triple seals prevent leakage
TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
ACTUAL OE or EQUIVALENT HIGH IGNITABILITY DESIGN: DFE tip and iridium alloy center electrode produce the most advanced OE spark plug technology
IRIDIUM ALLOY CENTER ELECTRODE: Iridium's density (6x that of platinum) and extremely high melting point is perfect for modern high efficiency engines
DFE DESIGN: Double fine electrode (platinum pin) provides more complete fuel burn, quicker throttle response, smoother idle and better cold starts

Specifications

Center Electrode Core Material	Copper
Center Electrode Design	Fine Wire
Center Electrode Insulator Tip Projection	4.0 mm
Center Electrode Projection	Mid Projection
Center Electrode Tip Material	Iridium
Country Of Origin	JP
Electrical Terminal Type	Non-Removable Nut
Grade Type	Performance
Ground Configuration	J-Gap
Ground Electrode Core Material	Nickel
Ground Electrode Quantity	1
Ground Electrode Tip Design	Dual Fine Electrode (DFE) - High Ignitability
Ground Electrode Tip Material	Platinum
Hex Size	5/8" (16mm)
Insulator Height	50.5 mm
Insulator Material	Ceramic
Manufacturer Heat Range	5
Metallurgy	Iridium Platinum
Part Number	DILFR5A11
Pre-Gap Size	1.1 mm
Reach	26.5 mm
Resistance	5000.0 82
Resistor Type	Yes
Seat Type	Flat
Service Number	DILFR5A11
Short Style Spark Plug	No
Skirt	No
Skirt Length	0.0 mm
Street Legal	Yes
Thread Size	M14 - 1.25
Thread Type Standard	Metric
Washer Type	Crush
Washer(s) Included	Yes

Warranty

2 Months

Magnuson-Moss Warranty Act

Legally, a vehicle manufacturer cannot void the warranty on a vehicle due to an aftermarket part unless they can prove that the aftermarket part caused or contributed to the failure in the vehicle (per the Magnuson Moss Warranty Act (15 U.S.C. 2302(C)).
