86-11 HD Evo 883 Overbore 1200 9.51 CR Piston Kit

Part Number K1655 (132854339)
Package contents: 1 Each
Select vehicle for guaranteed fit
$402.99 $447.95 SAVE 10% FREE SHIPPING

In stockShips by 18th Nov
FREE SHIPPING

Description

  • Forged from a high-silicone aluminum alloy to deliver long life and consistent dimensions
  • Wiseco’s high-tech manufacturing ensures greater operating strength and lower expansion at high temperatures
  • Sold in kits that include two pistons, rings, piston pins and circlips
  • Include forged pistons with coated skirts, rings, retainer clips and chrome piston pins
  • Piston kits are available with X-Ring package (.062 top ring, .062 compression ring and .158 oil ring), XC-Ring packages (.039 top ring, .062 compression ring, .158 oil ring) or VM-rings (1.2mm steel, positive twist, gas nitrided top ring, 1.2mm cast iron, taper under-hook scraper ring and 2.0mm three-piece, flex-vent oil ring with steel chrome-faced rails); VM-rings, X-Rings and XC-Rings will not interchange
  • X- and XC-rings are identified by PART # in the application chart; X-Ring PART #s end with an “X” and XC-Ring Part #s end with an “XC”
  • 103” kits require cylinder boring; 110” kit requires big-bore cylinders and case boring; X-Ring package (.0472” top ring, .0472” compression ring and .118” oil ring); recalibration required
  • Pistons are made in the U.S.A.

NOTES:Replacement rings include rings for one piston only. Wiseco pistons that use VM-rings can only be fitted with Wiseco VM-rings; Wiseco pistons that use XC-rings can only be fitted with Wiseco XC-rings.

Fitment

This part fits the following vehicles.

Harley-Davidson

  • 2016-2020 XL1200CX Roadster
  • 2012-2016 XL1200V Seventy-Two
  • 2010-2020 XL1200X Forty-Eight
  • 2018-2019 XL1200XS Forty-Eight Special
  • 1999-2009 XL883C Sportster 883 Custom
  • 2005-2010 XL883L Sportster 883 Low
  • 2012-2019 XL883L SuperLow
  • 2009-2022 XL883N Iron 883
  • 2002-2003, 2005-2007 XL883R Sportster 883 Roadster
  • 1991-2009 XL883 Sportster
  • 1986-1987 XLH1100
  • 1988-2003 XLH1200
  • 1986-2004 XLH883
  • 1986-1995 XLH883DLX Sportster 883 Deluxe
  • 1987-2003 XLH883HUG Sportster 883 Hugger
  • 2009-2010 XR1200
  • 2010-2012 XR1200X

Features & benefits

  • Improved tensile strength of forged material optimizes strength and service life
  • Optimized compression ratio to fit your build and performance goals
  • Designed and built for each specific 4-stroke powersports engine
  • Dedicated forgings allow for optimized strength-to-weight ratio
  • Designed and built specifically for each V-Twin engine platform
  • Includes high-quality piston rings, wrist pin(s), and circlips
  • Engineered, forged, and machined in the USA in Mentor, OH
  • Wrist pin, rings and circlips included
  • 3.498 in. Bore, 9.5:1 CR

Specifications

Barcode 00193564149718
Dimensions 9.6" x 5" x 4"
Weight 3.24 lbs

California residents

WARNING: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov.

Carb Status

California carb status to be completed
