Description
RECOMMENDED FOR: Heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains.
For the past century Gates has been powering progress as one of the world’s leading parts manufacturers in the automotive industry, working with virtually every Original Equipment Manufacturer worldwide to design products for new vehicles as they are being developed. These strong relationships together with Gates commitment to continuous innovation enable us to offer a complete line of OE quality products for the Aftermarket. From Timing Belts to Micro-V Belts, Tensioners and Hose, for both import and domestic vehicles, install with confidence, install Gates.
Features & benefits
- Oil-resistant tube.
- CAUTION: Not recommended for conveying liquids.
- For standard–duty applications.
Specifications
| Country Of Origin | USA |
|---|---|
| Coupling Recommendation | See Catalog for Recommendation |
| Cover Color | Black |
| Cover Material | Chloroprene - Type A |
| Cover Type | Standard |
| Dash Size | 88 |
| Industrial Description | 88EH7000 |
| Inside Diameter (in) | 5.5 |
| Inside Diameter (mm) | 139.7 |
| Length (ft) | 10 |
| Maximum Working Pressure (Bar) | .7 |
| Maximum Working Pressure (psi) | 10 |
| Minimum Bend Radius (in) | 12 |
| Minimum Burst Pressure (psi) | 40 |
| Outside Diameter (in) | 5.75 |
| Outside Diameter (mm) | 146.1 |
| Product Type | Air Duct Hose (8-20) SD |
| Reinforcement | Multi-Ply, Synthetic Textile, Dual Wire Helix |
| Temperature Range | -30 Deg. F to +250 Deg. F (-34 Deg. C to +121 Deg. C) |
| Tube Description | Black; Chloroprene - Type A; Oil Resistant |
| Tube Material | Chloroprene - Type A |
| Type | Air & Multi-Purpose Hose |
| Vacuum (inHg) | 6 |
