OE Series Laser Platinum Spark Plug: Fine Wire Tip, PFR7AB

Part Number 93322 (132648968)

UPC: 87295833223

Package contents: 1 Each

Select vehicle for guaranteed fit

$22.47

In stockShips by 26th Oct

Description

NGK Laser Platinum spark plugs provide high ignitability and longer service life compared to conventional nickel spark plugs. Laser Platinum plugs are tested to the highest standards to ensure quality and durability. Engineered specifically for OE applications. Laser platinum plugs provide stable idling, superior anti-fouling, improved fuel efficiency and lower emissions. High-grade pure alumina ceramic and 98% pure copper core prevents spark plug from overheating and provides reliable starts. Most Laser Platinum spark plugs feature a platinum pad on the ground electrode for even wear in distributorless ignition systems.

Fitment

This part fits the following vehicles.

2016-2019 Ski-Doo Expedition Xtreme E-TEC 800R
2012-2017 Ski-Doo Freeride E-TEC 800R 137
2012-2017 Ski-Doo Freeride E-TEC 800R 146
2012-2017 Ski-Doo Freeride E-TEC 800R 154
2012-2015 Ski-Doo GSX SE E-TEC 800R
2016-2017 Ski-Doo MX Z Blizzard E-TEC 800R
2011-2016 Ski-Doo MX Z TNT E-TEC 800R
2011-2016 Ski-Doo MX Z X E-TEC 800R
2011-2017 Ski-Doo MX Z X-RS E-TEC 800R
2011-2016 Ski-Doo Renegade Adrenaline E-TEC 800R
2011-2017 Ski-Doo Renegade Backcountry E-TEC 800R
2011-2017 Ski-Doo Renegade Backcountry X E-TEC 800R
2016-2018 Ski-Doo Renegade Enduro E-TEC 800R
2011-2016 Ski-Doo Renegade X E-TEC 800R
2015-2017 Ski-Doo Renegade X-RS E-TEC 800R
2016-2017 Ski-Doo Summit Burton E-TEC 800R
2011 Ski-Doo Summit Everest E-TEC 800R
2011 Ski-Doo Summit Freeride E-TEC 800R
2012-2017 Ski-Doo Summit SP E-TEC 800R 146
2012-2017 Ski-Doo Summit SP E-TEC 800R 154
2012-2016 Ski-Doo Summit SP E-TEC 800R 163
2017 Ski-Doo Summit SP E-TEC 800R 174
2016 Ski-Doo Summit SP T3 Package E-TEC 800R 154
2016 Ski-Doo Summit SP T3 Package E-TEC 800R 163
2016 Ski-Doo Summit SP T3 Package E-TEC 800R 174
2011-2015 Ski-Doo Summit X E-TEC 800R 146
2011-2015 Ski-Doo Summit X E-TEC 800R 154
2011-2015 Ski-Doo Summit X E-TEC 800R 163
2017 Ski-Doo Summit X E-TEC 800R 174
2016 Ski-Doo Summit X T3 Package E-TEC 800R 154
2015-2016 Ski-Doo Summit X T3 Package E-TEC 800R 163
2015-2016 Ski-Doo Summit X T3 Package E-TEC 800R 174

Features & benefits

Pure alumina silicate ceramic insulator provides superior strength and better heat transfer
Trivalent metal plating for superior anti-corrosion and anti-seizing properties
RECOMMENDED USAGE: Best for vehicles with OE fine wire platinum alloy plugs
Corrugated ribs prevent flashover
Copper core aids in heat removal
Triple seals prevent leakage
SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
PLATINUM ALLOY CENTER ELECTRODE: Longer wearing and higher temperature resistance compared to traditional nickel spark plugs
TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction fine wire platinum alloy center electrode provides consistent performance
PLATINUM TIP GROUND ELECTRODE: Unless OE specified, platinum protection at the ground electrode provides excellent ignitability and service life

Specifications

Center Electrode Core Material	Copper
Center Electrode Design	Fine Wire
Center Electrode Insulator Tip Projection	3.5 mm
Center Electrode Projection	Mid Projection
Center Electrode Tip Material	Platinum
Color	Platinum
Country Of Origin	JP
Electrical Terminal Type	Non-Removable Nut
Grade Type	Performance
Ground Configuration	J-Gap
Ground Electrode Core Material	Nickel
Ground Electrode Quantity	1
Ground Electrode Tip Design	Standard
Ground Electrode Tip Material	Platinum
Hex Size	5/8" (16mm)
Indexed	Yes
Insulator Height	50.5 mm
Insulator Material	Ceramic
Manufacturer Heat Range	7
Metallurgy	Double Platinum
Part Number	PFR7AB
Pre-Gap Size	0.8 mm
Reach	19.0 mm
Resistance	5000.0 82
Resistor Type	Yes
Seat Type	Flat
Service Number	PFR7AB
Short Style Spark Plug	No
Skirt	No
Skirt Length	0.0 mm
Street Legal	Yes
Thread Size	M14 - 1.25
Thread Type Standard	Metric
Washer Type	Crush
Washer(s) Included	Yes

Warranty

2 Months
