Racing Spark Plug: Conventional Tip, BR8EG

Part Number 3130 (132648105)

UPC: 87295031308

Package contents: 1 Each

Select vehicle for guaranteed fit

$4.56

In stockShips by 29th Oct

Description

NGK Racing spark plugs are designed with extreme use in mind and meant to withstand the most grueling racing conditions. NGK Spark Plugs have been powering racing champions and can be found in every racing venue throughout the world. The center electrode of the NGK Racing spark plugs has special configurations and designs to ensure durability and ignitability. NGK Racing plugs bring ultra high performance in a variety of heat ranges. Special configurations are used for a wide variety of racing applications.

Fitment

This part fits the following vehicles.

2010-2012 Gas Gas EC 250
2011-2012 Gas Gas EC 250E
2010 Gas Gas EC 250 Racing
2010-2012 Gas Gas EC 300
2011-2012 Gas Gas EC 300E
2002-2004 Gas Gas MC 250
1982-1986, 1989-2004 Honda CR250R
1982-1983 Honda CR480R
1984-2001 Honda CR500R
2002-2004 Husqvarna CR250
2002-2006, 2010-2012 Husqvarna WR250
2009-2012 Husqvarna WR300
1996 250 KTM EXC
1996 250 KTM SX
1996 300 KTM EXC
1996 300 KTM MXC
1996 360 KTM EXC
1996 360 KTM MXC
1996 360 KTM SX
2001-2008 Suzuki RM250
2004 Suzuki RMZ250
1983, 1996-2019 Yamaha YZ250
2016-2019 Yamaha YZ250X

Features & benefits

TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
Pure alumina silicate ceramic insulator provides superior strength and better heat transfer
Special insulator nose configurations improve throttle response
Corrugated ribs prevent flashover
Copper core aids in heat removal
Triple seals prevent leakage
DESIGNED FOR RACING: Conventional nickel alloy center electrode provides consistent performance
NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
RECOMMENDED USAGE: Racing use only, featuring special configurations and designs to ensure durability and ignitability
SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges

Specifications

Center Electrode Core Material	Copper
Center Electrode Design	Fine Wire
Center Electrode Insulator Tip Projection	1.0 mm
Center Electrode Projection	Non-Projected
Center Electrode Tip Material	Nickel
Country Of Origin	JP
Electrical Terminal Type	Removable Nut
Grade Type	Performance
Ground Configuration	J-Gap
Ground Electrode Core Material	Nickel
Ground Electrode Quantity	1
Ground Electrode Tip Design	Standard
Ground Electrode Tip Material	Nickel
Hex Size	13/16"
Insulator Height	53.8 mm
Insulator Material	Ceramic
Manufacturer Heat Range	8
Metallurgy	Copper
Part Number	BR8EG
Pre-Gap Size	0.6 mm
Reach	19.0 mm
Resistance	5000.0 82
Resistor Type	Yes
Seat Type	Flat
Service Number	BR8EG
Short Style Spark Plug	No
Skirt	No
Skirt Length	0.0 mm
Street Legal	Yes
Thread Size	M14 - 1.25
Thread Type Standard	Metric
Washer Type	Crush
Washer(s) Included	Yes
