NGK Authorized Dealer

92005 SILNAR9C7DG Laser Iridium Spark Plug

Part Number 3235 (132648408)
Package contents: 1 Each per Box
PERFORMANCE PART
$116.01

In stockShips by 18th Nov

Description

NGK Racing spark plugs are designed with extreme use in mind and meant to withstand the most grueling racing conditions. NGK Spark Plugs have been powering racing champions and can be found in every racing venue throughout the world. The center electrode of the NGK Racing spark plugs has special configurations and designs to ensure durability and ignitability. NGK Racing plugs bring ultra high performance in a variety of heat ranges. Special configurations are used for a wide variety of racing applications.

Features & benefits

  • NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
  • TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
  • COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
  • DESIGNED FOR RACING: Surface discharge tip design built to withstand extreme heat and vibration
  • SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
  • RECOMMENDED USAGE: Racing use only, featuring special configurations and designs to ensure durability and ignitability
  • Pure alumina silicate ceramic insulator provides superior strength and better heat transfer
  • Special insulator nose configurations improve throttle response
  • Corrugated ribs prevent flashover
  • Copper core aids in heat removal
  • Triple seals prevent leakage

Specifications

Barcode 00087295032350
Center Electrode Core Material Copper
Center Electrode Design Standard
Center Electrode Insulator Tip Projection 0.3 mm
Center Electrode Projection Non-Projected
Center Electrode Tip Material Nickel
Country Of Origin JP
Dimensions 4.3" x 3.6" x 0.9"
Electrical Terminal Type Stud
Grade Type Performance
Ground Configuration Surface Discharge
Ground Electrode Core Material Nickel
Ground Electrode Quantity 0
Ground Electrode Tip Design Surface Discharge
Ground Electrode Tip Material Nickel
Hex Size 5/8" (16mm)
Insulator Height 49.5 mm
Insulator Material Ceramic
Manufacturer Heat Range 9
Metallurgy Copper
Part Number R0045Q-9
Pre-Gap Size 1.1 mm
Reach 19.0 mm
Resistance 5000.0 82
Resistor Type Yes
Seat Type Flat
Service Number R0045Q-9
Short Style Spark Plug No
Skirt No
Skirt Length 0.0 mm
Street Legal Yes
Thread Size M10 - 1.0
Thread Type Standard Metric
Washer Type Flat
Washer(s) Included Yes
Weight 0.33 lbs

Warranty

2 Months
